    3 In 1 Plastic Auxiliary Equipment Feeding Dehumidifying Dryer Machine

    High quality 3 in 1 feeding-dehumidifying -dryer machine for PET preform production dehumidification dry feed
    XMD mold dehumidifier is mainly used in plastic molding, because the mold using chilled water to shorten the molding cycle and condensation problems, in particular, PET bottle embryos the most suitable. Condensation phenomenon is when the mold shows that the temperature is lower than the surrounding ambient air dew point temperature will produce water vapor, which affects the product quality and efficiency, while corrosion of the mold surface, and cause environmental pollution. The machine uses the honeycomb wheel system dehumidification operation to ensure that the mold around the 0-10 ℃ always maintain the low dew point of the air environment, so that the phenomenon of condensation caused by the mold is also not affected by seasonal changes, significantly reducing the defect and the rejection rate.
    Features:
    ▪ With P.I.D temperature control system, with regenerative temperature setting and actual temperature display screen;
    ▪ 24 hours automatic operation timing setting, and automatic fault display function;
    ▪ Honeycomb design, dehumidification dryness and stability;
    ▪ Motor overload and reverse phase alarm function;
    ▪ Total power switch with mechanical interlock function;
    ▪ return air cooling and filtration function;
    ▪ Optional digital dew point detector with high dew point indication and alarm;
    ▪ Under normal atmospheric conditions, the humidity can be precisely controlled throughout the year;
    ▪ extend the life of the mold, reduce corrosion, improve product yield;
    ▪ The dry air temperature of the outlet to the mold is about 30 ° C, which does not cause the temperature around the mold to be too low to expose the firing window.
    ▪ Immediately with detachable return air collectors for closed-loop applications, especially in tropical climates.

    The main technical parameters

    Model numberXD-80u/
    90H
    XD-120u/
    90H
    XD-160u/
    120H
    XD-230u/
    150H
    XD-300u/
    200H
    XD-450u/
    300H
    XD-600u/
    400H
    XD-750u/
    500H
    XD-900u/
    700H
    XD-900u/
    700H
    Drying system
    Insulation capacity (L)801201602303004506007509001200
    Dry electric power (kw)3667.2121518212424
    Dry fan power (kw)0.551.12.22.23345.55.55.5
    Dehumidification system
    Dehumidification air volume (m/hr)9090120150200300400500700700
    Regenerative heating power (kw)2.83.53.545.47.27.2101010
    Regenerative fan power (kw)0.370.370.550.550.750.751.11.12.22.2
    Feeding system
    Feeding fan power (kw)1.751.751.751.752.22.22.22.22.22.2
    Suction piping (inch)1.51.51.51.51.51.51.51.522
    Electric eye hopper (L)66612121212121212
    Ordinary hopper(L)666666661212
    Dimensions (mm)Long1200120013001500160017001700210021002100
    Width1000100011001360136014001400150015001500
    High1870187019002060206023002300270027003200
    Weight(kg)330376395435570600700750850950
